Printing on Both Sides of the Paper
Phaser® 8560/8860 Printer
3-30
Printing Side Two
1. Remove the paper from the output tray and reload it in the paper tray:
■ Tray 1: Insert side two facedown with the top of the page entering the printer first.
■ Tray 2, 3, or 4: Insert side two faceup with the top of the page toward the front of the
tray.
2. Select 2nd Side on the control panel:
3. In t he printer driver, select 2nd Side as the paper type or the appropriate tray as the paper
source.
Tray 1 Tray 2, 3, or 4
a. Select Change setup , and then press
the OK button.
b. Select the appropriate paper size, and
then press the OK button.
c. Select 2nd Side , and then press the
OK button.
a. Select Paper Tray Setup , and then
press the OK button.
b. Select either Tray 2 Paper Type ,
Tray 3 Paper Type , or Tray 4 Paper
Type (depending on the tray you are
using), and then press the OK button.
c. Select 2nd Side , and then press the
OK button.
