E-9
Host Command Summary
Select segment for GIN cursor
ESC I C *
GINCURSOR *
◆ Select tablet area
ESC I N *
TBSIZE *
Set GIN stroke report frequency
ESC I F *
GINFILTERING *
Specify GIN cursor movement
ESC I U *
GINRATES *
Specify GIN key characters
ESC I Z *
GINTABCHARS *
Specify GIN stroke report key characters
ESC I H *
GINSHEADERCHARS *
Specify tablet type
ESC I B *
GRAPHICS ALPHA TEXT
HOST
PRIMARY SETUP
Select alpha text font (G0)
ESC SI
Select alpha text font (G1)
ESC SO
Select underline mode
ESC L M *
DAMODE *
Specify 4014 alpha text size (128 cpl)
ESC ;
Specify 4014 alpha text size (128 cpl)
ESC :
Specify 4014 alpha text size (80 cpl)
ESC 8
Specify 4014 alpha text size (80 cpl)
ESC 9
GRAPHICS PRIMITIVES
HOST
PRIMARY SETUP
Change graphics position
ESC L F *
MOVE *
Define line style
ESC M X *
LSDEFINE *
Draw curve
ESC U C *
CURVE *
Draw marker
ESC L H *
MARKER *
Draw vector
ESC L G *
DRAW *
End panel definition
ESC L E
ENDPANEL
◆ Fill rectangle
ESC U R *
RECTANGLE *
Finish fill pattern definition
ESC M E
ENDFILLP
Select marker style
ESC M M *
MARKTYPE *
Select panel fill pattern
ESC M P *
FILLPATTERN *
Select panel filling features
ESC M S *
PFILLMODE *
◆ Select pixel rectangle features
ESC R T *
PXFACTORS *
◆ Select rectangle drawing boundary
ESC U B *
BOUNDMODE *
Specify 4014 line style (* = ` to o)
ESC *
Specify style of line/panel boundary
ESC M V *
LINESTYLE *
Start fill pattern definition
ESC M D *
BEGINFILLP *
Start panel definition
ESC L P *
BEGINPANEL *
GRAPHICS SURFACES
HOST
PRIMARY SETUP
Erase graphics area
ESC FF
Select current view surf./erase/border index
ESC R A *
VATTRIBUTES *
Select surface visibility
ESC R I *
SVISIBILITY *
Specify number of surfaces & bit planes
ESC R D *
SDEFINITIONS *
Specify surface priority level
ESC R N *
SPRIORITIES *
GRAPHICS TEXT
HOST
PRIMARY SETUP
Begin graphics text character definition
ESC S T *
GTBEGIN *
Define graphics text font grid dimensions
ESC S G *
GTGRID *
Delete user defined character from font
ESC S Z *
GTDELETE *
Display graphics text
ESC L T *
GTEXT *
End graphics text character definition
ESC S U
GTEND
Graphics area replace/overstrike
ESC M G *
GAMODE *
