Page 9
Printer Components
Chapter 1: Introduction
1-3
Printer Components
Use Figures 1.1 through 1.3 to identify the main components of
your DocuPrint P1202.
Figure 1.1 Printer Components, Front View
Front View
Face down output stacker
Paper support
Multi-Purpose Tray (MP Tray)
Tray 1 (250 sheet)
Tray 2 (250 sheet, optional)
Control board cover
(provides access to SIMM slots for
adding/removing additional memory)
Control panel
Paper level indicators
Figure 1.2 Printer Components, Inside Front View
Inside Front View
Top cover
Laser print cartridge
Serial number
Top cover release button
