Serial/LocalTalk Card
B-8 DocuPrint P1202 Reference Guide
Serial/LocalTalk Card
The Serial/LocalTalk option lets you connect your DocuPrint
P1202 to a PC or Macintosh serial interface, or to a Macintosh
LocalTalk network.
To use the serial connection, a standard 9-pin serial cable is
required. One end has a 9-pin female connector and the other end
has a 9-pin male connector. Do not use a null-modem cable,
which is a twisted pair cable.
Review the precautions on page B-3 and then follow this procedure
to install the Serial/LocalTalk option in your computer.
1
Turn the printer power off and disconnect the power cord.
2
Remove the control board cover.
