ES-4024A Series Switch Support Notes
All contents copyright (c) 2006 ZyXEL Communications Corporation.
65
ES-3124(config-interface)# pvid 20
ES-3124(config-interface)# exit
ES-3124(config)# interface port-channel 14
ES-3124(config-interface)# pvid 20
Step 7: On the ES-3124, set the PVID of specific VLAN 30
ES-3124(config)# interface port-channel 5
ES-3124(config-interface)# pvid 30
ES-3124(config-interface)# exit
ES-3124(config)# interface port-channel 15
ES-3124(config-interface)# pvid 30
Step 8: On the ES-3124, set the PVID of specific VLAN 40
ES-3124(config)# interface port-channel 6
ES-3124(config-interface)# pvid 40
ES-3124(config-interface)# exit
ES-3124(config)# interface port-channel 16
ES-3124(config-interface)# pvid 40
Step 9: On the ES-3124, in the configure mode, enable IGMP snooping
ES-3124(config)#igmpsnooping
Step 10: On the ES-3124, in the configure mode, create MVR
ES-3124(config)# mvr 100
Step 11: Define the Dynamic mode
ES-3124(config-mvr)# mode dynamic
Step 12: on the ES-3124, in the MVR 100, set up the multicast group
address.
ES-3124(config-mvr)# group test start-address 233.1.1.1
end-address 233.1.1.100
Step 13: In the MVR 100, specify receiver ports on port 14~16 as tagged
ports
ES-3124(config-mvr)# receiver-port 14-16
ES-3124(config-mvr)# untagged 14-16
