ES-4024A Series Switch Support Notes

8. Now, you need to tell the Switch how you are going to separate the

physical Switch into some logical small Switches. Thus, we click

“Advanced Application” then “VLAN”. On the right screen, check the

boxes to suit your need. In this case, we need to make port 1~4 and

port 9, 10 in a group in order for them to communicate in both ways.

And port 5~10 in another group but these two groups cannot talk with

each others. Here we also logically defined Port 9 and Port 10 as the

uplink ports. Therefore, both groups can pass data to Port 9 and Port

10. In another word, these two ports belong to both of the groups on

the same time. Please confirm if your setting looks similar to below.
