ES-4024A Series Switch Support Notes


All contents copyright (c) 2006 ZyXEL Communications Corporation.

40

Configuring your Switch to fulfill this scenario (CLI)

1. Connect the Switch Console port with your PC or Notebook.

2. Open your Terminal program.(Ex, Hyper Terminal in Windows

System)

3. Make sure that your port settings are

bps:9600

Data bits:8

Parity: None

Stop bits:1

Flow control: None:

4. After you connected successfully, give the correct user name and

password.

5. Put “en” or “enable” to go into the privileged mode. Then put “config” to

go into the configuration mode.

6. Put the following commands to setup Port Based VLAN on your Switch

in this
