16
WATLOW Series 733/734 Service Manual Setup Mode, Chapter 2
Parameter Value Range Factory Default Appears If:
C_F C or F F
gb 1 to 4000°F/2222°C 4000°F/2222°C
rtd JIS or din din Input type is RTD
tncP On or OFF OFF
tS hrnn or nnSc nnSc
SIL On or OFF OFF Unit has alarms,
AL1 no & AL2 no
LAt LA or nL nL Unit has alarms,
AL1 no & AL2 no
InP1 J, K (appears as H), E or rtd J or rtd Dependent on model
number information
rL1 Sensor range low to rH1 Low limit sensor type
rH1 Sensor range high to rL1 High limit of sensor type
HYS1 1 to 99°F/1 to 55°C 3°F
AL1 Pr, dE or no Pr Unit has alarms
A1LO If AL1 = dE: 0 to -999°F/ -999°F Unit has alarms &
0 to -555°C AL1 no
If AL1 = Pr: rL1 to A1HI rL1
A1HI If AL1 = dE: 0 to 999°F/ 999°F Unit has alarms &
0 to 555°C AL1 no
If AL1 = Pr: A1LO to rH1 rH1
CAL1 -99 to 99°F/-55 to 55°C/-99 to 99Units 0
InP2 J, K (appears as H), E or J or rtd or 0-5 Dependent on model
rtd or 0-5, 420, 010, 020 number information
rL2 Sensor range low to rH2 Low limit sensor type Hardware is present
rH2 Sensor range high to rL2 High limit of sensor type Hardware is present
HYS2 1 to 99°F/1 to 55°C/ 1 to 99 units 3°F Hardware is present
AL2 Pr, dE or no Pr Hardware is present
A2LO If AL2 = dE: 0 to -999°F/ -999°F Hardware is present &
0 to -555°C/0 to -999 Units AL2 no
If AL2 = Pr: rL2 to A2HI rL2
A2HI If AL2 = dE: 0 to 999°F/ 999°F Hardware is present &
0 to 555°C/0 to 999 Units AL2 no
If AL2 = Pr: A2LO to rH2 rH2
CAL2 -99 to 99°F/-55 to 55°C/-99 to 99Units 0 Hardware is present
Setup
Table 2 -
Setup Mode
Parameters and
Descriptions.
Setup Mode
Use this page as a master copy for your Series 733/734 Setup mode parameters.
Do not enter any values here; make photocopies instead.
