Whirlpool 1997 "E" - Manual (Page 16)

2-6
REMOVING THE CONTROL PANEL
WARNING
Personal Injury Hazard
Disconnect from the electrical supply be-
fore servicing the unit. Failure to do so
could result in death or electrical shock.
2. Remove the two screws from the top of
the cabinet for the vent grille and remove
the grille (see the illustration on page
2-3).
3. Remove the screw from the top center tab
of the control panel, then lift the panel so
that the bottom tabs are out of the slots
and pull it forward.
4. Turn the panel over and disconnect the
three harness connectors from the board,
then set the control panel aside.
TURN PANEL OVER
CONTROL PANEL
CONTROL
PANEL SCREW
BOTTOM
TABS
BOTTOM
SLOTS
1. Disconnect the electrical supply to the
microwave oven.
