3. Angle the battery up from the bay and gently slide it out. (Figure 3.2)
4. Angle the new battery into the bay. The front edge of the battery
should slide into the grooves in the system case.
5. Gently lower the battery into the bay and push it until it “clicks”
securely in the bay. Reconnect the AC Adapter.
When you install a new battery, you will need to calibrate the battery.
Install the new battery and connect the AC adapter. Let the battery charge
fully. Then, turn on the power and press [F2] when prompted to enter the
Figure 3.2: Changing the Battery
3.4
Series
User’s Manual
Above: Pull up on the tab and
the battery will pop-up. Top
right: Lift the battery out. Right:
Remove the battery.
