Western Digital 4CH TRIPLEX - Manual (Page 38)

Captured images are sorted by date/time, which indicates the time of recording. Select a
file from the list to view the captured image.
To capture a still image and view, please refer to “5-8. Still Image Capturing, Viewing, and
Viewing.”
4-5-5. SEND MAIL (IP ADDRESS Mailing)
If the network is linked with LAN-DHCP or ADSL, which support dynamic IP addresses, DVR
can send out the dynamic allocated IP addresses by mails. It is unnecessary for a distant user
to confirm the IP address when he/she connects to the network since he/she can view it after
receiving it by email.
1. Press buttons to decide whether to send mail or not by selecting or
.
Move the cursor to MAIL ADRESS field and press SEL button to type in the mail address on
the keyboard that appears.
To type @, press “Caps Lock” button. Then @ will appear on the top line.
38
