Cooktop Chimney Hood Installation
11
wolfappliance.com/specs
Install Ductwork
CHIMNEY WALL HOODS
CHIMNEY ISLAND HOOD
DUCTWORK
INSTALLATION
THROUGH
WALL
21"
(535)
HOOD DEPTH
DUCTWORK INSTALLATION
THROUGH ROOF
24"
(610) TO
30"
(762)
BOTTOM OF
HOOD TO
COUNTERTOP
30
1
/
2
"
(775) TO
48
1
/
2
"
(1232)
OR
32
5
/
8
"
(829) TO
50
7
/
8
"
(1292)
TELESCOPING
HOOD HEIGHT
12"
(305)
DUCTWORK INSTALLATION
THROUGH ROOF
27"
(686)
HOOD DEPTH
24"
(610) TO
30"
(762)
BOTTOM OF
HOOD TO
COUNTERTOP
33
1
/
2
"
(851)
TO
47"
(1194)
TELESCOPING
HOOD HEIGHT
DUCTWORK
INSTALLATION
THROUGH
EAVE—
INTERNAL
BLOWER
12"
(305)
