Installation
Page 22
STEP 2: PEN TABLET INSTALLATION
USB CABLE INSTALLATION
Plug the USB connector into an available USB port on your computer or into a USB hub attached to
your computer. See – E – in the connection diagram below.
Next, move on to the pen tablet Software installation on page 23.
PEN TABLET USB CABLING DIAGRAM
Your computer
– E –
To Cintiq
To USB port
