AQUA PLUS

indirect

-

fired

water

heaters

— Product Manual

Domestic water piping

(continued)

LEGEND for Figure 2, page 6

Domestic water supplied to fixtures that could pose

an injury hazard due to high temperature, such as

showers and faucets, should be equipped with a

temperature regulating device, such as an

anti-scald

mixing valve

.

When the supply pressure is higher than 70 PSIG,

install a

pressure reducing valve

on cold water

supply line to prevent water loss through T&P relief

valve. A thermal expansion tank is also required.

This symbol, where used in this manual, indicates the

item is required by Massachusetts code.

This symbol indicates the item is optional, unless

required by applicable codes.

1

Domestic cold water inlet connection — see Fig-

ure 3, page 6 for size

2

Domestic hot water outlet connection — see Fig-

ure 3, page 6 for size

3

Domestic recirculation connection — see Fig-

ure 3, page 6 for size

4

Boiler water inlet to coil — see Figure 3, page 6 for size

5

Boiler water outlet from coil — see Figure 3, page 6 for

size

6

Drain valve — provided by installer

• Install a drain valve on the DHW inlet to the water heater

as shown.

7

Piping from drain valve

• Pipe from drain to floor drain, if available.

8

T&P valve connection

9

T&P relief valve — supplied with water heater

• Use only the T&P valve supplied with the water heater.

See Replacement parts for part number.

• Install the T&P relief valve in the top center tapping, as

shown.

10

T&P relief valve discharge piping —

• must be made of material serviceable for temperatures

of 250°F or greater.

• must be directed so that hot water flows away from all

persons.

• must be directed to a suitable place for disposal.
• must be installed so as to allow complete draining of the

T&P relief valve and discharge line.

• must NOT be excessively long — using more than 2 el-

bows or 15 feet of piping can reduce discharge capacity.

• must NOT be directly connected to a drain — terminate

discharge piping within 6” from floor — refer to local

codes.

• must NOT be plugged, reduced or restricted.
• must NOT be subjected to freezing.

Do not install any valve between T&P relief valve and

tank connection, or on T&P relief valve discharge

piping. Do not plug T&P relief valve or its discharge

piping. Improper placement and piping of T&P re-

lief valve can cause severe personal injury, death or

substantial property damage.

11

Temperature adjustment knob

12

Anode access

• The anode is specially made for this water heater. Use

only the anode available from Weil-McLain, as listed in

Replacement parts.

13

Mixing valve —

RECoMMENDED

• See Replacement parts for thermostatic mixing valves

available from Weil-McLain.

14

Domestic cold water supply

When the water supply pressure is higher than

70 PSIG, install a pressure-reducing valve on the

cold water supply line to prevent leakage from the

T & P relief valve. A thermal expansion tank is also

required.

15

Domestic mixed-temperature water supply to

system

(when used — requires mixing valve)

16

Domestic high-temperature hot water supply to

system

17

Heat trap loops (12” minimum) —

18

Isolation valves

19

Thermal expansion tank —

REQUIRED

if cold water line is equipped with a backflow

preventer or pressure reducing valve — see

ExPANSIoN

TANk WARNING

on page 6.

20

Shock arrester —

Dishwashers, clothes washers, and fast-closing positive

shutoff valves incorporated in the system all contrib-

ute to creating water shock. Install a water hammer

arrester to prevent damage to pipes and appliances.

See control manufacturer’s instructions for applica-

tion and installation.

21

Unions

• Use dielectric unions or couplings to protect hot and cold

water fittings from corrosion when connecting dissimilar

materials such as copper and galvanized iron pipe.

22

Backflow preventer —

(

required

for Commonwealth of Massachusetts)

23

Vacuum breaker —

24

Pressure reducing valve —

REQUIRED

when the supply pressure is higher than

70 PSIG —

A thermal expan

sion tank is also required

.

Part number GL-E223-ADOC 0311
