Ratings with 200°F boiler supply water
For water heater to achieve the rated performance below: Boiler water must be supplied to the water heater at 200°F,
and the boiler water flow rate must be no less than given in the tables below. (For
Ultra
Gas boiler,
Ultra
Oil boiler
or GV90+ boiler applications, with supply water at 190°F, see the ratings in the boiler manual.)
Boiler
Heating
Capacity
MBH
First Hour Rating Capacity (GPH) — Boiler Water Supply at 200°F
Do NoT exceed the boiler-side flow rate listed in “Maximum boiler-side flow rate,” page 23
DHW
temps
AQUA
PLUS
35
Boiler
Water
Min GPM &
Head Loss
AQUA
PLUS
45
Boiler
Water
Min GPM &
Head Loss
AQUA
PLUS
55
Boiler
Water
Min GPM &
Head Loss
AQUA
PLUS
85
Boiler
Water
Min GPM &
Head Loss
AQUA
PLUS
105
Boiler
Water
Min GPM &
Head Loss
50
DHW
50°F to 140°F
93
8 GPM
minimum
@
1.6 ft wc
103
8 GPM
minimum
@
1.6 ft wc
124
8 GPM
minimum
@
1.6 ft wc
138
14 GPM
minimum
@
5.4 ft wc
148
14 GPM
minimum
@
7.1 ft wc
70
120
130
151
165
175
90
147
157
178
192
202
110
174
184
205
219
229
130
201
211
232
246
256
150
223
237
259
273
283
170
223
243
286
300
310
190
223
243
302
327
337
210
223
243
302
354
363
250
223
243
302
374
417
300
223
243
302
374
483
350
223
243
302
374
483
400
223
243
302
374
483
450
223
243
302
374
483
500
223
243
302
374
483
50
DHW
50°F to 1
15
°F
119
8 GPM
minimum
@
1.6 ft wc
129
8 GPM
minimum
@
1.6 ft wc
150
8 GPM
minimum
@
1.6 ft wc
164
14 GPM
minimum
@
5.4 ft wc
174
14 GPM
minimum
@
7.1 ft wc
70
157
166
188
201
211
90
194
203
225
239
249
110
231
241
262
276
286
130
268
278
299
313
323
150
306
315
337
351
360
170
337
352
374
388
398
190
337
363
411
425
435
210
337
363
443
462
472
250
337
363
443
537
547
300
337
363
443
551
640
350
337
363
443
551
715
400
337
363
443
551
715
450
337
363
443
551
715
500
337
363
443
551
715
