Wagner SprayTech Twin Stroke Piston Pump 9146 - Manual (Page 5)

5 English
Components and Description
9146, 9150
9170
9190
GX-07
GX-07
GX-08
415
517
517
517
519
521
Yellow (fine)
9140S GX-05 415 415 Yellow (fine)
White (medium)
White (medium)
25 feet
25 feet
50 feet
50 feet
This pump is available in two models: a stand model (9140S) and cart models (9146, 9150 shown below, 9170 and 9190). All
information given for the stand model applies to the cart models except where indicated.
Oiler (9146, 9150,
9170 and 9190only)
Spray hose port
(reverse side)
ON / OFF switch*
(reverse side)
Pail bracket
Pusher stem
Suction set filter
Suction tube
Return tube
Clip
Hose bracket
PRIME/SPRAY
knob
Return tube
fitting
Spray hose
Spray gun (see chart above
for models, GX-07 shown)
Spray
guard
Spray tip
(see chart above
for models)
**The pump cleaning
adapter can be clipped
to the spray hose port
Pump cleaning
adapter**
Pressure control dial
(rear of sprayer)
Important
Some of the graphics in this manual may not exactly match your sprayer and spray gun. All information and instructions
given in this manual applies to all models except where noted.
