19 English
1. Fill a cup or other container with separating oil
(approximately 2 ounces) supplied with the unit and
submerge the inlet valve into the oil. Light household oil
can be substituted.
2. Place a rag over the spray hose port, and turn the switch
ON (l). When the oil has been sucked from the cup, turn
the pump OFF (O).
3. Wipe the entire unit, hose and gun with a damp cloth to
remove accumulated paint. Replace the high pressure
hose to the paint hose port.
Separating oil
Follow these instructions only after all cleanup steps have been performed.
If you have a cart model (9146, 9150, 9170, 9190), you can collapse the cart handle for easier storage.
1. Twist the knobs on either side of the cart
counterclockwise.
2. Slide the handle into the cart.
Long-Term Storage
