15 English
1. Lock the gun and remove spray tip assembly. Submerge
suction set into a bucket with appropriate cleaning
solution.
2. Place a waste container next to the original material
container. Aim the spray gun into the side of the original
material container and hold the trigger.
Bucket with
cleaning
solution
3. While pulling the gun trigger, turn the pump ON (l), and turn
the PRIME/ SPRAY knob to SPRAY to purge material from
the hose back into the original container.
• Hold trigger
• Turn pump ON (l)
• Turn PRIME/SPRAY knob to SPRAY
Containers should
be touching
Original
material
container
Hold trigger
Waste
container
Move on to Cleaning the Suction Set.
4. When cleaning solution flows from the spray gun, keep
holding the trigger and aim the spray gun into the side of the
waste container
(ground gun with a metal container if
flushing with flammable solvent).
5. Trigger the gun until the fluid flowing out of the gun is
clear. You may need to dispose and obtain new cleaning
solution.
6. Turn the PRIME/SPRAY knob to PRIME and trigger gun
to relieve pressure.
Spray cleaning solution
into waste container
Spray material into
original container
Hold
trigg
er
Keep holding trigger through next steps.
Cleanup -
Oil-based materials
