3 English
HAZARD: GENERAL
Can cause severe injury or property damage.
PREVENTION:
• Read all instructions and safety precautions before operating
equipment.
• Follow all appropriate local, state, and national codes governing
ventilation, fire prevention, and operation.
• The United States Government Safety Standards have been
adopted under the Occupational Safety and Health Act (OSHA).
These standards, particularly part 1910 of the General Standards
and part 1926 of the Construction Standards should be consulted.
• Use only manufacturer authorized parts. User assumes all risks
and liabilities when using parts that do not meet the minimum
specifications and safety requirements of the pump manufacturer.
• Before each use, check all hoses for cuts, leaks, abrasion or
bulging of cover. Check for damage or movement of couplings.
Immediately replace the hose if any of these conditions exist.
Never repair a paint hose. Replace it with another grounded high-
pressure hose.
• All hoses, swivels, guns, and accessories must be pressure rated
at or above 3000 PSI/207 BAR.
• Do not spray outdoors on windy days.
• Wear clothing to keep paint off skin and hair.
• Do not operate or spray near children. Keep children away from
the equipment at all times.
• Do not overreach or stand on an unstable support. Keep effective
footing and balance at all times.
• Stay alert and watch what you are doing.
• Do not operate the unit when fatigued or under the influence of
drugs or alcohol.
Important Electrical Information
NOTICE
Use only a 3-wire extension cord that has a 3-blade grounding plug and
a 3-slot receptacle that will accept the plug on the product. Make sure
your extension cord is in good condition. When using an extension
cord, be sure to use one heavy enough to carry the current your
product will draw. An undersized cord will cause a drop in line voltage
resulting in loss of power and overheating. A 14 or 12 gauge cord is
recommended (see chart below). If an extension cord is to be used
outdoors, it must be marked with the suffix W-A after the cord type
designation. For example, a designation of SJTW-A would indicate that
the cord would be appropriate for outdoor use.
Do not use more than 100 feet of spray hose. If you need to
spray further than 100 feet from your power source, use
more extension cord, not more spray hose.
Cord gauge Maximum cord length
12 200 feet
14 100 feet
NOTICE
THE 9140S, 9146 AND 9150 SERIES UNITS ARE PROVIDED WITH A
NON-RESETABLE THERMAL OVERLOAD. THE 9170 AND 9190
SERIES UNITS ARE PROVIDED WITH A REPLACEABLE FUSE.
• Always disconnect the motor from the power supply before working
on the equipment.
Grounding Instructions
This product must be grounded. In the event of an electrical short
circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current. This product is equipped with a
cord having a grounding wire with an appropriate grounding plug. The
plug must be plugged into an outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
Improper installation of the grounding plug can
result in a risk of electric shock.
If repair or replacement of the cord or plug is necessary, do not connect
the green grounding wire to either flat blade terminal. The wire with
insulation having a green outer surface with or without yellow stripes is
the grounding wire and must be connected to the grounding pin.
Check with a qualified electrician or serviceman if the grounding
instructions are not completely understood, or if you are in doubt as to
whether the product is properly grounded. Do not modify the plug
provided. If the plug will not fit the outlet, have the proper outlet
installed by a qualified electrician.
This product is for use on a nominal 120 volt circuit and has a
grounding plug that looks like the plug illustrated below. Make sure that
the product is connected to an outlet having the same configuration as
the plug.
No adapter should be used with this product.
If you experience problems with your
sprayer at any time during assembly,
operation, or cleanup, please refer to
the Troubleshooting section of this
manual (page 22), or call customer
service at:
1-800-880-0993
Grounded Outlet
Grounding Pin
Cover for grounded outlet box
WARNING
The cause of the overload should be corrected before
restarting. Take unit to Service Center.
Important Safety Information
• Read all safety information before
operating the equipment. Save these instructions
