A p p l i c a t i o n 8

Wa t l o w M

I N I

C

H E F

2 0 0 0

1 9

With Sound set to 4 or 5, [``end] will appear on the display and the Start/Stop
key indicator light will flash rapidly. You must acknowledge the audible signal by
pressing the Start/Stop key. Once acknowledged the audible signal is silenced and
the controller goes into idle. The Start/Stop key indicator light will be off.

5.

Once the controller goes into idle, the Start/Stop key indicator light and the heat
outputs will switch off. The controller will not regulate to any temperature.

6.

To repeat cooking, repeat steps 1 through 3 or 4.

Pause a Menu

While cooking, you can pause cooking time by pressing the Start/Stop key once. The
Start/Stop key indicator light will flash rapidly. [PAUSE] will appear on the display.
Countdown time will resume when you press the active menu key again.

Cancel a menu

Canceling a menu stops the controller completely. The controller does not maintain set
point temperatures or run time. You cancel a menu to run another menu, stop menu
operation for any reason, or are preparing to shut off the oven.

Press the Start/Stop key for 2 seconds. Heat outputs will switch off. Heat output
indicator lights will switch off. [`idLE] or time of day will be on the display.

Change Menus or Restart

With the controller in idle:

1.

Select a menu as shown earlier.

2.

Press the Start/Stop key.

Door Opening

When you open the oven door (when the oven door is open, the switch is closed and
Event Input 1 is turned on) the unit will act as described below.

During the cooking sequence: time is paused - [`door] will appear on the display.

The heat and fan output signals will shut off.

During the preheat sequence: [`door] will appear on the display. The heat and fan
output signals will be shut off.

When you close the door the unit will operate normally.

Event Outputs

While running a menu when the Configuration Mode [EtYPE] / [FAn``] is set to
[````2] :
When Low fan speed is on, Event Output 1 is on.
When High fan speed is on, Event Output 2 is on.

While running a menu when the Configuration Mode [EtYPE] / [FAn``] is set to
[````1] :When the fan is on, Event Output 1 is on.

ç

WARNING: Starting or initiating a menu can cause or initiate fan motion. Appropriate reasonable care should be

taken to prevent personal injury or machine damage as a result of operator initiated or unexpected fan motion.
