User's Manual - 95
Group: iva_i<0~2>
PARAMETER VALUE Default SECURITY
(get/set)
DESCRIPTION
name string[40] Trigger<1~3> 4/4 The identification of this entry.
enable 0, 1 0 4/4 To enable or disable this Video
content analysis.
type move,
loiter,
obstruct
Obstruct 4/4 The type of the trigger.
Delay 1~999 10 4/4 How many seconds when the
object(s) loiter in the region
should the event be triggered.
region_i<0~4>_name string[40] NULL 4/4 The name of the region.
region_i<0~4>_points string[40] NULL 4/4 The coordinates of the points.
For example. 72,(the x of point 1)
90,(the y of point 1) 202, (the x of
point 2) 42,…
Drive the digital output
Note: This request requires the privilege of viewer.
Method: GET/POST
Syntax:
http://<servername>/cgi-bin/dido/setdo.cgi?do1=[&do2=]
[&do3=][&do4=][&return=]
Where state is 0, 1. “0” means inactive or normal state while “1” means active or triggered state.
PARAMETER VALUE DESCRIPTION
0 – inactive, normal state do 0, 1
1 – active, triggered state
return
Redirect to the page after the parameter is
assigned. The can be a full URL path or relative
path according the the current path. If you omit this
parameter, it will redirect to an empty page.
