User's Manual - 107
Technical Specifications
All specifiations are subject to change without notice All other trademarks are owned by their respective companies P/N:011001500 Ver 1�0
Specifications
Networking
Η10/100 Mbps Ethernet, RJ-45
ΗProtocols: IPv4, TCP/IP, HTTP, UPnP, RTSP/RTP/RTCP, IGMP,
SMTP, FTP, DHCP, NTP, DNS, DDNS, and PPPoE
Alarm and Event Management
ΗTriple-window video for motion detection
Η
One D/I and one D/O for external sensor and alarm
ΗEvent notification using HTTP, SMTP, or FTP
ΗLocal recording of MP4 files
Security
ΗMulti-level user access with password protection
ΗIP address filtering
Users
ΗCamera live viewing for up to 10 clients
Dimension (including lens)
Η 205.5 mm (D) x 82.1 mm (W) x 51.2 mm (H)
Weight (including lens)
ΗNet: 545 g
LED Indicator
ΗSystem power and status indicator
ΗSystem activity and network link indicator
Power
Η12V DC, 24V AC
Η
Consumption: Max 7.5 W
Η802�3af compliant Power over Ethernet
Approvals
ΗCE, FCC, C-Tick, LVD, VCCI
Operating Environments
ΗTemperature: 0° ~ 50° C ( 32° ~ 122° F)
ΗHumidity: 20 % ~ 80 % RH
Viewing System Requirements
Η OS: Microsoft Windows 2000/XP/Vista
Η Browser: Internet Explorer 6.x or above
ΗCell phone: 3GPP player
ΗReal Player: 10�5 or above
ΗQuick Time: 6�5 or above
Installation, Management , and Maintenance
Η Installation Wizard 2
Η16-CH recording software
ΗSupports firmware upgrade
Applications
ΗSDK available for application development and system integration
Networking
Η10/100 Mbps Ethernet, RJ-45
ΗProtocols: IPv4, TCP/IP, HTTP, UPnP, RTSP/RTP/RTCP, IGMP,
SMTP, FTP, DHCP, NTP, DNS, DDNS, and PPPoE
Alarm and Event Management
ΗTriple-window video for motion detection
Η
One D/I and one D/O for external sensor and alarm
ΗEvent notification using HTTP, SMTP, or FTP
ΗLocal recording of MP4 files
Security
ΗMulti-level user access with password protection
ΗIP address filtering
Users
ΗCamera live viewing for up to 10 clients
Dimension (including lens)
Η 205.5 mm (D) x 82.1 mm (W) x 51.2 mm (H)
Weight (including lens)
ΗNet: 545 g
LED Indicator
ΗSystem power and status indicator
ΗSystem activity and network link indicator
Power
Η12V DC, 24V AC
Η
Consumption: Max 7.5 W
Η802�3af compliant Power over Ethernet
Approvals
ΗCE, FCC, C-Tick, LVD, VCCI
Operating Environments
ΗTemperature: 0° ~ 50° C ( 32° ~ 122° F)
ΗHumidity: 20 % ~ 80 % RH
Viewing System Requirements
Η OS: Microsoft Windows 2000/XP/Vista
Η Browser: Internet Explorer 6.x or above
ΗCell phone: 3GPP player
ΗReal Player: 10�5 or above
ΗQuick Time: 6�5 or above
Installation, Management , and Maintenance
Η Installation Wizard 2
Η16-CH recording software
ΗSupports firmware upgrade
Applications
ΗSDK available for application development and system integration
System
ΗCPU: VVTK-1000 SoC
ΗFlash: 8MB
ΗRAM: 64MB
ΗDSP:TI DM642
Η
Embedded OS: Linux 2.4
Lens
ΗCS-mount, vari-focal, f=2�9 mm ~ 8�2 mm, auto-iris
ΗIR Corrected
ΗRemovable IR-cut filter for day & night function
Angle of view
Η 26.7° ~ 69.0° (horizontal)
Η 20�0° ~ 51�0° (vertical)
Shutter Time
Η1/30 sec� to 1/15000 sec�
Image Sensor
Η SONY 1/4” Progressive scan CCD sensor in VGA resolution
Minimum Illumination
Η 1.0 Lux/F1.0
Video Content Analysis
ΗCamera tampering detection
ΗIntelligent moving object detection
ΗMoving object loitering detection
Video
ΗCompression: MJPEG & MPEG-4
ΗStreaming:
Simultaneous dual-streaming
MPEG-4 streaming over UDP, TCP, or HTTP
MPEG-4 multicast streaming
MJPEG streaming over HTTP
ΗSupports 3GPP mobile surveillance
Η
Frame rates: 640x480 up to 30fps (60 Hz)/25fps (50Hz)
Image settings
Η Adjustable image size, quality, and bit rate
Η Time stamp and text caption overlay
ΗFlip & mirror
ΗConfigurable brightness, contrast, and saturation
ΗAGC, AWB, AES
ΗAutomatic or manual day/night mode
ΗBacklight compensation (BLC)
ΗSupports privacy masks
Audio
ΗCompression:
GSM-AMR speech encoding, bit rate: 4�75 kbps to 12�2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
ΗInterface:
Built-in microphone
External microphone input
Audio output
ΗSupports two-way audio by SIP protocol
ΗSupports audio mute
System Overview
IP7251
PC with
Recording Software
Indented
Reset Button
General I/O
Terminal Block
Power Cord
Socket
MIC In
Ethernet 10/100
RJ45 Socket
External/Internal
MIC Switch
Audio Out
