VIVOTEK - A Leading Provider of Multimedia Communication Solutions


52 - User's Manual

■ Digital input

Select one of the Digital inputs to allow the Network Camera to use external digital input device as a
trigger source� Depending on your applications, there are choices of digital input devices on the market
which helps to sense any changes in temperature, vibration, sound and light, etc�

■ System boot

Select this option to allow the Network Camera to trigger when the power of Network Camera is
disconnected�

Event Schedule: The effective period in which the event stays active� Specify the effective period for the
event�

■ Select the days on weekly basis.

■ Select the time for recording in 24-hr time format.

Action

: Also referred as the effect, defines the action to be performed by the Network Camera when the

trigger is activated� Select the action to perfom when a trigger is activated�

■ Trigger D/O for seconds

Select this option to turn on external digital output device when a trigger is activated. Specify the length

of trigger interval in the text box.

Server name / Media name

Select the server and media name to allow the Network Camera to send the media files to the server
when a trigger is activated�

When completed, select Enable this event� Click Save to take effect and then click Close to quit this
page� The new event name will appear in the event drop-down list on the application page� To remove an
event setting from the list, select an event name from the drop-down list and then click Delete�
