VM4016 Command Dictionary 51
T ABLE 4-2: I NSTRUMENT S PECIFIC SCPI C OMMANDS
Command Description RST RST Value
FETCh:CONDitioned? Reads back the 16-bit value that
represents the current conditioned
(masked and inverted) output state of
the comparators in the group.
FETCh:LATChed? Read back the 16-bit value that was
latched when the first input(s) in the
group caused an active edge.
FETCh:RAW? Reads back the 16-bit value that
represents the current unconditioned
(no masking or inversion) output state
of the comparators in the group.
INHOUSE:PSEUDO Sets the type of register interface used.
INHOUSE:REGINT Controls type of interrupt response X 0
INHOUSE:REG_ENABLE Interrupt masking X 0
INHOUSE:CLEAR_LATCH Controls clearing of first latched
information.
X 0
INPut:DEBounce This sets the debounce timing on a
group of the analog comparators. X 19.2 µs
INPut:MASK Sets the masking for a group of
channels X 0
INPut:MASK:INTerrupt Enable or disable interrupt generation
when changing MASKs X 0
INPut:OFFSet Sets the comparator threshold for a
group of channels. X 0.469 V
INPut:POLarity Sets the polarity for a group of
channels. X NORMAL
INPut:RANGe Sets the range for a group of channels. X 100
OUTPut:POLarity:EXTernal:INTerrupt Sets the polarity for the interrupt
output on the front panel for one of the
three groups.
X NORMAL
OUTPut:POLarity:EXTernal:LATChed Sets the polarity for latched interrupt
output on the front panel for one of the
three groups.
X NORMAL
