VXI Technology, Inc.

VM4016 Programming

OUTPUT:POLARITY:EXTERNAL:INTERRUPT

The output polarity external interrupt command sets the polarity of the front panel interrupt
output. When the polarity is set to normal, the output will be low when there is an interrupt event.
When the polarity is set to invert, the output will be high when there is an interrupt event.

OUTPut:POLarity:EXTernal:INTerrupt

Where is either
NORMal or INVert.

EXAMPLES

OUTPut:POLarity:EXTernal:INTerrupt NORM

Sets the external interrupt output
polarity to a low pulse (NORMal),
when an interrupt occurs.

OUTPut:POLarity:EXTernal:INTerrupt?

Returns the external interrupt

NORM

output polarity as NORMal.

OUTP:POL:EXT:INT INV

Sets the external interrupt output
polarity to INVert.

OUTP:POL:EXT:INT?

Returns the polarity of the external

INV

interrupt output as INVert.
