VXI Technology, Inc.
14 VM4016 Introduction
VM4016 G ENERAL S PECIFICATIONS
G ENERAL S PECIFICATIONS
C HANNELS
VM4016-1
VM4016-2
VM4016-3
16
32
48
I NPUT R ANGE
±10.0 V, ±100 V
I NPUT T HRESHOLD R ESOLUTION
±10.0 V
±100.0 V
78 mV
780 mV
I NPUT T HRESHOLD A CCURACY
±3%
I NPUT T YPE
Differential, may be configured for single-ended by grounding the negative input
I NPUT I MPEDANCE
200 kΩ differential
100 kΩ single-ended
I NPUT P OLARITY
Rising or falling edge
D EBOUNCE T IME
9.6 μs to 0.6291456 s, 9.6 μs resolution
IRQ O UTPUT
Open Collector Driver, 200 mA max. sink
Internally pulled up to +5 V with 10 kΩ resistor
L ATCHED IRQ O UTPUT
Open collector driver, 200 mA max. sink
Internally pulled up to +5 V with 10 kΩ resistor
VXI I NTERFACE
Message-based word serial interface
Direct register access in the user defined area of the VXIbus register map
L OGICAL A DDRESSING
Static or dynamic configuration
R AW D ATA R EGISTER
Logical address + 20H
M ASKED D ATA R EGISTER
Logical address + 28H
F IRST L ATCHED R EGISTER
Logical address + 30H
P OWER R EQUIREMENTS
VM4016-1
VM4016-2
VM4016-3
+5 V @ 1.43 A, -5.2 V @ 0.17 A, +24 V @ 0.05 A, -24 V @ 0.05 A
+5 V @ 2.12 A, -5.2 V @ 0.29 A, +24 V @ 0.10 A, -24 V @ 0.10 A
+5 V @ 2.81 A, -5.2 V @ 0.41 A, +24 V @ 0.15 A, -24 V @ 0.15 A
C OOLING R EQUIREMENTS
VM4016-1
VM4016-2
VM4016-3
See Power Cooling Table
See Power Cooling Table
See Power Cooling Table
