VT1422A Command Reference 363 Chapter 7
[SENSe]
•
Send with VXIplug&play Function: hpe1422_cmd(...)
Usage SENS:STRAIN:BRID Q120,(@10000:10031)
configure strain RSC unit channels 00-31
connected to on-board channel 00 to 120
ohm quarter bridge
[SENSe:]STRain:BRIDge:[TYPE]?
[SENSe:]STRain:BRIDge[:TYPE]? (@<channel>) returns the VT1529A/B’s
bridge configuration for channel specified by <ch_list>.
Parameters
Comments •
The <channel> parameter must be a single channel only.
•
Returned Value: one of "FBEN" | "HBEN" | "Q120" | "Q350" | "USER".
The data type is string.
•
Related Commands: SENSE:STR:BRID[:TYPE]
•
*RST Condition: SENS:STR:BRID:TYPE FBEN for all VT1529A/B channels
•
Send with VXIplug&play Function: hpe1422_cmdString_Q(...)
Usage SENS:STRAIN:BRID (@10022)
check strain RSC unit channel 22 bridge
configuration connected to on-board
channel 00
[SENSe:]STRain:CONNect
[SENSe:]STRain:CONNect ,(@<ch_list>) connects the VT1529A/B channels specified by <ch_list> to sense either the strain bridge output or the bridge
excitation supply. Only one channel for each VT1529A/B needs to be specified in
<ch_list> and all channels on that unit will configure as specified in <select>.ParametersComments•Related Commands: SENSE:STRAIN:…, SENSE:FUNC:STRAIN…•*RST Condition: SENS:STR:CONN BRIDGE for all VT1529A/B channels.ParameterNameParameterTypeRange ofValuesDefault Unitschannelchannel list (string)10000 - 15731noneParameterNameParameterTypeRange ofValuesDefault Unitsselectdiscrete (string)BRIDge | EXCitationnonech_listchannel list (string)10000 - 15731none Pages: 1 … 363 364 365 366 367 … 529 wrong Brand wrong Model non readable This manual is related to the following products: VT1529A/B Sitemap connects the VT1529A/B
channels specified by <ch_list> to sense either the strain bridge output or the bridge
excitation supply. Only one channel for each VT1529A/B needs to be specified in
<ch_list> and all channels on that unit will configure as specified in <select>.
Parameters
Comments •
Related Commands: SENSE:STRAIN:
…, SENSE:FUNC:STRAIN…
•
*RST Condition: SENS:STR:CONN BRIDGE for all VT1529A/B channels.
Parameter
Name
Parameter
Type
Range of
Values
Default
Units
channel channel list (string) 10000 - 15731 none
Parameter
Name
Parameter
Type
Range of
Values
Default
Units
select discrete (string) BRIDge | EXCitation none
ch_list channel list (string) 10000 - 15731 none
