Toro TDC-100/200 User Manual
Page 6
16
Power LED
17
Daughter Board Fuse (8), 3.15A Fast-Blow
Daughter Board Components
6
6
1
Station Watering LED
2
Pump ON LED
3
Pump Pressure LED
4
Rain Sensor LED
5
Power LED
6
PC Connection LED
7
Tx LED
8
Rx LED
9
Mother Board Fuse, 3.15A Slow-Blow
10
Timing Mechanism Cable Socket
11
RS-232 Fiber/Wire Switch
12
Pump Output
13
Pump Pressure Input
14
Rain Switch Input
15
RS-232 Input
Mother Board Components
Mother Board
Daughter Board
1
2
3
4
5
6
7
8
15
14
13
12
11
10
16
9
17
