Page 16

The percent adjust function allows you to fine tune irrigation programs. With weather conditions changing

constantly, Percent Adjust allows you to tune your system easily without changing all the values in the program.

Important: The settings do not override each other, instead, they multiple each other to get the effective adjustment.

Example: Controller is set at 150%, Program is set at 125% and Station is set at 90%. The effective watering
adjustment is calculated to be 1.5 x 1.25 x 0.9 = 1.68 or 168%.

% Adjust Directions

1. Press the % Adjust Key

. The cursor is initially located at the System % Adjust field. Use the Input Dial

to adjust the controller watering up to 900% or down to 1%.

Note:

The controller adjustment will affect all stations and programs universally. Do not adjust the System %

settings if adjustment is station or program specific.

2. Press the Down Arrow

to advance the cursor to the Program: field. The first entry field will be the

program selection field. Use the Input Dial

to select the program being adjusted. Press the Right

Arrow

to advance the percent adjustment field. Use the Input Dial

to adjust the program

watering up to 250% or down to 10%. Repeat step 2 to adjust additional programs.

Note:

Do not adjust the program % setting if adjustment is station specific.

3. Press the Down Arrow

to advance the cursor to the Station: field. The first entry field will be the station

selection field. Use the Input Dial

to select the station being adjusted. Press the Right Arrow

to advance to the percent adjustment field. Use the Input Dial

to adjust the station watering up to

900% or down to 000%. Repeat step 3 to adjust additional stations.

Note:

Adjusting the station’s watering to 000% will prevent it from running within a program. Multi-Manual and

Syringe are not affected by the % Adjustment.

The Start key is used to execute a manual function.

Note:

Pressing the Start key while the controller is idle will prompt the Manual Watering menu.

Multi-Manual Start Display

Manual Syringe Start Display

Manual Start Program Display

Syringe Starting

Program 01

STOP to cancel

Multi-Manual

Starting

STOP to cancel

Start Key

Percent Adjust...
Global:

100%

Program : P01

100%

Station : S01

100%

% (Percent) Adjust

Global will adjust from 1–250%
Program will adjust from 10–250%
Station will adjust from 0–250%
