Toro TDC-100/200 - Manual (Page 17)

The Pause command is used to suspend active program or manual irrigation. The Pause function allows the
user to specify the pause duration.
Pause / Resume Function Directions
Pause function example: Program 01 has been manually activated. Pause program 01 for 30 minutes.
1. Press the Pause key.
2. Use the Input Dial to select All, M-Man or Prg:XX (XX = the program number). If multiple programs
are active, use the Right Arrow key to tab to the program number field before using the Input Dial to
select the correct program number. For this example, select Prg: 01.
3. Press the Down Arrow to advance the cursor to the for: field. Use the Input Dial and the
Right Arrow key to select the pause duration in hours and minutes. For this example, set the pause
duration to 00 hr 30 min.
The display should read:
Note: The default pause time is 00 hr 05 min minutes.
4. Press the Pause key to initiate the Pause function.
Resume Controller Activity example: Reactivate Program 01 watering.
1. Press the Pause key.
2. Use the Input Dial until the correct program or multi-manual operation is displayed.
For this example, select Resume: Prg: 01.
The display should read:
3. Press the Pause key to release the Pause function.
Resume: Prg: 01
Press PAUSE to pause
01 Programs Paused
Pause: Prg: 01
for: 00hr 30 min
Press PAUSE to pause
00 Programs Paused
Pause / Resume Key
