59
)
Note:
Be sure to change the router's default password to a very secure password. In AP mode, port 80
is only supported. The web management port number will be set to 80 when the operation mode
changes to AP mode.
4.13.11 Statistics
The Statistics page (shown in Figure 4-61) displays the network traffic of each PC on the LAN,
including total traffic and traffic of the last
Packets Statistic interval seconds.
Figure 4-61 Statistics
¾ Current Statistics Status - Enabled or Disabled. The default value is disabled. To
enable, click the Enable button. If disabled, the function of DoS protection in Security
settings will be ineffective.
¾ Packets Statistics Interval - The default value is 10. Select a value between 5 and 60
seconds from the pull-down list. The Packets Statistic interval indicates the time section
of the packets statistic.
¾ Sorted Rules - Here displays sort as desired
Statistics Table:
IP Address The IP Address displayed with statistics
Packets The total amount of packets received and transmitted by the router.
Total
Bytes The total amount of bytes received and transmitted by the router.
Packets
The total amount of packets received and transmitted in the last Packets
Statistic interval
seconds.
Bytes
The total amount of bytes received and transmitted in the last Packets
Statistic interval
seconds.
ICMP
Tx The total amount of the ICMP packets transmitted to WAN in the last
Packets Statistic interval
seconds.
Current
UDP
Tx
The total amount of the UDP packets transmitted to WAN in the last
Packets Statistic interval
seconds.
