Trango Broadband High Density Mesh System - Manual (Page 8)

HD Mesh Node
Trango Broadband Wireless — High Density MESH page 8
Location of RJ-45/LED Port
The RJ-45 connectors for Trango Power Over Ethernet (PoE) injectors are located at the bottom of the
mounting plate inside the HD Mesh box. The router ports and serial port are located at the top of the
mounting plate. The PoE diagnostic LEDs are located on the face lid of the mounting plate. Functionality of
the LEDs is described later in this text. (Figure 4)
Figure 4
HD MESH Management
The HD Mesh unit can be configured using a Command Line Interface (CLI), Web Browser (HTTP) interface,
or Winbox (GUI) interface. Although all methods are comprehensive and powerful, the CLI method provides
more functionality.
Password
The HD Mesh unit is pre-configured with the following default account and password. This user name
and password will allow you to gain access via CLI, HTTP, or Winbox.
User Name admin
Password trango
Note: The password will default to a blank password if the unit is set to factory defaults. The user name will still
be admin.
ROUTER
POE
