Section 6 Default Configuration
The HD Mesh node is configured with the first 5 ports as router ports, each with their own IP address.
The ports are also configured to give out DHCP IP addresses. Ports 6, 7, and 8 are configured to act as a
single bridge. The bridge is configured with an IP Address and also as a DHCP server. The wireless card is
configured with its own IP address and also as a DHCP Server. Port 9 is configured as a DHCP client. (Figure
41)
Port IP address Bridge Comments
Ether 1 192.168.1.1/24 No
DHCP Server issues IP addresses from
DHCP range 192.168.1.50-100
Ether 2 192.168.2.1/24 No
DHCP Server issues IP addresses from
DHCP range 192.168.2.50-100
Ether 3 192.168.3.1/24 No
DHCP Server issues IP addresses from
DHCP range 192.168.3.50-100
Ether 4 192.168.4.1/24 No
DHCP Server issues IP addresses from
DHCP range 192.168.4.50-100
Ether 5 192.168.5.1/24 No
DHCP Server issues IP addresses from
DHCP range 192.168.5.50-100
Ether 6 N/A Yes Bridge port 1
Ether 7 N/A Yes Bridge port 1
Ether 8 N/A Yes Bridge port 1
Ether 9 No DHCP Client- NAT
WLAN 1 192.168.1.10/24 No 802.11b/g SSID: HDMESH
Bridge 1 192.168.7.1/24
DHCP Server issues IP addresses from
DHCP range 192.168.7.50-100
Figure 41
