Introduction to the "Functions and Operating Instructions" for stations for EXES-6000
This handbook explains the functions and operating
procedures of stations for TOA's EXES-6000 Intercom
System using central processing unit CP-63 (for tie-line
system) and exchanges EX-610/620.
Designed for connection of up to 3 exchanges, the EXES-
6000 system permits you to talk with the person in the
remote area, and also to increase the number of stations
which one (1) exchange cannot cover.
This handbook deals with
1. Explanation of the tie-line system and restrictions of
each function (See items 2, 4 through 6 and 11)
2. Basic use of each station (See items 3 and 8 through 10).
3. Functions and dial operations (See items 4 through 7
and 11)
Please note that performances of some functions are
restricted in the tie-line system.
You need not read all the instructions given in this hand-
book but it is necessary to read the instructions on those
functions employed in your system. The following guide-
lines will help you select the pages that you should read.
Selecting different functions made available by placing the
Privacy Switch in the "ON" position
The EXES-6000 System is designed to allow either "PV"
"NP" type (Without Privacy function) to be selected by
sible to make one station the "NP" type and another the
"PV" type in the same system.
Type
"PV" Type and "NP" Type
Definition Description
PV Type System having
Privacy function 1. Privacy tone
With the Privacy switch in
the ON position, a brief
Privacy tone sounds and
any incoming call is refused.
2. The Handset Master/Sub-
station may not be used in
this system. If used, it is
not called by a continuous
calling tone but by a brief
Privacy tone.
System having
no Privacy func-
tion NP Type 1. Continuous calling tone
A station with the Privacy
switch may be called by the
continuous calling tone
when its Privacy switch is
placed in the ON position.
One touch dialing any key
2. The Handset Master
station without Privacy
switch may be called by
the continuous calling
tone. Picking up the hand-
set stops the calling tone
and allows the conversation.
key or picking up the
handset stops the calling
tone and the stations is
made ready to initiate the
response to the call.
Note.
By programming, the continuous calling tone function
may be made available to specific stations with the
Privacy switch in the OFF position.
In this event, touch dialing any key (
through
other than the key stops the calling tone
and permits conversation.
This feature may be employed for the industrial type of
station (Model HF-650M) or in the "PV" type system
that needs to be continuously called.
The function provided when the Privacy switch is in the ON
position is different between the "PV" and the "NP" type.
Therefore, read the page marked if your system
is of the "PV" type and the Page if it is of the
"NP" type.
— 2 —
type operation (The system having Privacy function) or
turning on or off a switch inside the exchange. It is impos-
