4.4 Video Cassette Recorder
h) Connect the video recorder to the SCART input marked „VCR“.
If the receiver is turned on, press the VCR key to play a video cassette. If the receiver is in standby
mode (see 6.1) all audio and video signals are directed to the SCART output TV, provided the VCR
produces an adequate switching signal.
4.5 Decoder
i) Plug the additional decoder to the SCART input marked „DECODER“.
You can toggle between four decoder signals to adapt to different decoding types.
A: „flat“, B: Baseband, C: Video unapplied, D: Video.
Consult the decoder’s user manual to find out which signals are required and select the signal type according to
the description in chapter 7.6, „Setting up the decoder“.
5 Installation
Calling the installation menu
> Press to switch the receiver to standby mode.
> Press and on the receiver at the same time and hold the keys down for appr. 2
secs.
> Press briefly.
> Press after terminating the settings to return to standby mode.
5.1 Basic setting
You can use the following settings to reset the receiver to its „original state“. Consequently, all the
changes and settings you have chosen will be undone. The pre-programmation (see 8) is
permanently stored and can be re-called anytime.
> Display the installation menu (see above)
> Press to set pointer to „Basic Setting“
> Press .
8
Installation menu
> basic setting
language
outdoor unit
satellite scan
autom. satellite scan
decoder/OSD
childproof control feature
ext. programmation
^/v/OK/STANDBY
Basic setting
> delete all
load the pre-programmation
^/v/OK/STOP
OK
VCR
Netz
