5.4 Satellite scan
The description of the scan feature assumes the following:
a) The antenna trajectory has been duly adjusted.
b) You have set up the right outdoor unit (see 5.3, „Outdoor unit“).
c) You have mounted the linear/circular polarizer (part no. 2206 or
2207) according to the instructions.
d) You know the westernmost and the easternmost satellites
through antenna orientation.
e) The actuator’s limit sensors have been adjusted such that the
motor is switched off before the mechanical limits of the
antenna retaining system are exceeded in order to avoid
damage on the paraboloidal-type reflector or the retaining
system.
> Display the installation
menu (see p. 8).
> Press to set pointer
to „satellite scan“.
> Press
> Press to set pointer
to „Satellit“.
> Press to select the easternmost satellite
(the example shows ASTRA 19.2° East)
> Press to set pointer to „Antennen-Posit“
(antenna position).
> Press to turn off background.
Moving the antenna: Upon start-up the antenna begins to move
slowly, but speeds up until you press the same key again.
> Briefly press .
Now, the antenna should move East. If the antenna moves West,
press to halt and change the order of the wire connections.
> Press briefly when you have found a satellite.
> Press to make an exact set-up.
> Press to set pointer to „Gesp. Position“ (stored position).
> Press to store (press to delete).
> Press to set pointer to „Ostgrenze“ (East limit).
> Press or to store (the East limit is stored 10 pulses further
East automatically).
> Press to set pointer to „Satellit“.
> Press to select the westernmost satellite
(the example shows Hispasat 1 at 30° West).
> Press to set pointer
to „antenna-position“.
(antenna position)
> Briefly press .
> Briefly press when you
have found a satellite.
11
Satellite scan
> satellite ASTRA 19.0
channel PRO7 11.406 GHz
stored position
antenna position
5000
west limit 0000
east limit 9999
antenna control LNB 1
optimise skew 117
^/v//MENU/OK/STOP
satellite scan
> satellite ASTRA 19,2O
channel PRO7 11.406 GHz
stored position 5048
antenna pos. 5048
West limit 0000
East limit 5058
antenna control LNB 1
optimise skew 175
^/v//MENU/OK/STOP
OK
MENU
