TW-H6W1IR ISDN Remote Router
18 Installation
To have incoming calls directed to a device on a PHONE jack, you
must enter the telephone number for the phone in the console program
under the Interface Configuration, ISDN submenu.
Step 5 - Connecting Ethernet Cables to the Router
Your TW-H6W1IR has six ports for connecting 10BASE-T Ethernet
devices to form a LAN. The jacks for ports 1 through 5 are wired to let
you connect network end nodes (computers, servers, bridges, other
routers, etc.) using standard “straight-through” EIA (Electronic
Industries Association) Category 3 or higher twisted-pair cables. The
jack for the sixth port is labeled Uplink and is wired to let you connect
to another 10Mbps Ethernet or dual-speed hub using a straight-through
cable, or an end node using a cross-wired cable.
Please refer to the following chart when deciding on the type of cable
necessary for a given connection:
DEVICE PORT
USED DEVICE BEING
CONNECTED
PORT
TYPE
CABLE TO USE
Hub or Norma
l
Crossover (X)
Norma
l
Switch Uplink Straight-Through (||)
Router Server (or PC) Straight-Through (||)
Hub or Norma
l
Straight-Through (||)
Uplink Switch Uplink Crossover (X)
Server (or PC) Crossover (X)
