22 G9000 Installation and Operation Manual
TABLE 1.5.a Detail of Specifications
Rated Output kVA 80 100 160 225 300 500 750
Rated Output kW 72 90 144 202.5 300 500 750
AC INPUT
Configuration 3 phase, 3 wire
Voltage 480 V (+15% to -20%)
Frequency 60 Hz (+/-10%)
Power Factor >.99 Lagging at 25% – 115% Load
Input kVA
(Max Input kVA) 76 kVA
(86 kVA chg)
95 kVA
(107 kVA chg)
151 kVA
(170 kVA chg)
212 kVA
(238 kVA chg)
312 kVA
(336 kVA chg)
521 kVA
(560 kVA chg)
781 kVA
(840 kVA chg)
Walk-in Function 1 –30 Seconds (in 1 second increments)
Start-up Delay 1 –3600 seconds (selectable in 1 second increments)
Input Current
(Max Input Current) 91 A
(103 A)
114 A
(129 A)
181 A
(204 A)
255 A
(286 A)
376 A
(404 A)
626 A
(673 A)
939 A
(1010 A)
Input Current Limiter ~111% Full Load Input Current ~108% Full Load Input Current
Reflected Current THDi 3% max. at 60% – 100% load (no input filter required); 6% max. at 25% – 59% load.
STATIC BYPASS INPUT
Configuration 3 phase, 3 wire
Voltage 480 V ±10%
Frequency 60 Hz ±5%
Bypass Overload 1000% for 1 cycle 500% for 1 cycle
BATTERY
Type Lead Acid
Ride Through Application Specific
Nominal Voltage 480 Vdc
Minimum Voltage 400 Vdc
Float Voltage Up to 545 Vdc
DC Ripple Current
(w/o batteries) 9 Adc 9 Adc 11 Adc 18 Adc 19 Adc 32 Adc 48 Adc
DC Ripple Current (% of
Full Load DC Current) 4.7% 3.8% 2.9% 3.4% 2.7% 2.7% 2.7%
Max DC Charging Current 20 A 25 A 40 A 56 A 75 A 125 A 187 A
Max. Discharge Current 188 A 235 A 372 A 524 A 776 A 1292 A 1935 A
