16
English
9
Choose a suitable location for mounting of the
display. Possible locations of the display unit are:
• on the ventilation opening (close to the steering
wheel), using a car specific
clip (please refer
to your car dealer).
• on the dash board behind or closely behind the
steering wheel. Make sure it does not affect the
view.
10
The display can be mounted on both horizontal
and vertical surfaces. To change the mounting
orientation, loosen the hinge bolt, adjust the foot
orientation and tighten the hinge bolt firmly.
• Connect the display cable to the hub,
where labelled DIS.
11
Connect the car battery.
To install an advanced music mute with
the car handsfree
1
Disconnect the car battery.
2
See installation chart on page 3. Proceed as in steps
2-3 in the instructions “To install the car handsfree”
3
Cut the yellow music mute cable since it is not
needed when you have an advanced music mute.
See A in installation chart on page 3.
4
Connect the blue ignition sense cable to the ignition
of the car. See B in installation chart on page 3.
5
Connect the brown end of the advanced music mute
cable to the car stereo loudspeakers.
6
Connect the black and yellow ends of the advanced
music mute cable to the car stereo.
7
Proceed as in steps 6, 8-11 in “To install the car
You can buy an advanced music mute separately.
