This is the Internet version of the user's guide. © Print only for private use. 15
English
To install the car handsfree
1 Disconnect the car battery.
2 Place the electronic box under the dashboard
of the car. See also installation chart on page 2.
It is recommended that the upper side of the
electronic box faces the driver with no metallic
barrier between the box and the driver.
Use the velcro enclosed in the kit to fasten
the electronic box.
• Connect the hub to the electronic box,
where labelled .
• Connect the bundle of power cables (red and
black), music mute cable (yellow) and ignition
sense cable (blue) to the electronic box, where
labelled .
3 Connect the black power cable to negative ground.
Connect the red power cable, with the integrated fuse,
to the positive pole on the car battery. Please note that
supply voltages other than 12 volts may cause
damage to the equipment.
4 Connect the yellow music mute cable to the car
stereo. See A in installation chart on page 2.
5 Connect the blue ignition sense cable to the ignition
of the car. See B in installation chart on page 2.
6 Place the microphone on a fixed part of the car
interior, preferably in the middle above the wind
screen. Place it directed towards the driver and away
from the loudspeaker(s). Place it away from air flows
such as windows and ventilation. Make sure that the
cable is long enough to reach the electronic box.
• Connect the microphone to the electronic box,
where labelled .
7 Place the loudspeaker at least 50 cm (20 inches)
from the microphone. Make sure that the cable is long
enough to reach the electronic box.
• Connect the external loudspeaker to the electronic
box, where labelled .
8 Choose a suitable location, for the control unit, for
example near the emergency break. The driver must
be able to reach the keys of the control unit from the
normal driving position. Make sure that the cable is
long enough to reach the electronic box. To be able
to change the direction of how the cable leads away
from the control unit, you have to take off the bottom
cover, and then put it back again. Place the control
unit in the location you have chosen.
• Connect the control unit cable to the hub, where
labelled COM.
The car handsfree should be installed by authorized personnel.
The display and control unit must be placed so that in case
of a car accident, driver or passengers do not risk being hurt
by hitting them.
