TANDBERG Videoconferencing System
81
Advanced use
Network clocking
The network clock setting specifies the number of physical external clock signals.
Use ‘RS449/V35 Compatible’ when the external equipment provides two clock signals, one for transmit and one
for receive. The difference between RS449 and V35 is the cable only.
Use ‘X21 Compatible’ when the external equipment provides a common clock signal for both transmit and
receive.
Cable Specification, V.35
V.35/RS-366 cable
Signal Name
Female
Male 34pin
Male 25pin
Comments
26pin DSUB
Winchester
DSUB
Pin number
Pin number
Frame ground
1
A
Signal ground
19,23
B
TX(A), transmit data
11
P
Twisted pair
TX(B)
12
S
RX(A), receive data
13
R
Twisted pair
RX(B)
14
T
RCLK(A), rcv clock
15
V
Twisted pair
RCLK(B)
16
X
TCLK(A), xmt clock
17
Y
Twisted pair
TCLK(B)
18
AA
DTR
26
H, C
RI
24
L, J
RLSD
22
F
RS366 DPR
2
2
RS366 ACR
3
3
RS366 CRQ
4
4
RS366 PND
5
5
RS366 DLO
6
22
RS366 NB1
7
14
RS366 NB2
8
15
RS366 NB4
9
16
RS366 NB8
10
17
RS366 GND
19
7
Cable Marking
NET
DSU V.35
DSU RS366
