TANDBERG Videoconferencing System
15
Installation
T HE CAMERA SHOULD BE ALIGNED WITH THE FRONT EDGE OF THE MONITOR TO ENSURE THE IR- SENSOR IN THE CAMERA CAN PICK UP SIGNALS
FROM THE REMOTE CONTROL .
Installing
Installing the monitor(s)
We recommend that there are 3 people present when installing the monitor(s).
•Remove the plastic plugs located on the back of the monitor(s). Check to see where the holes in the Monitor
Rack are located.
•Take the monitor(s) and place it (them) inside the Monitor Rack.
•Secure each monitor with the 8mm hexagonal-shaped screws.
•Remove the protective plastic film from the monitor front.
Installing the camera
Take the camera and remove the plastic backing from the double-sided pads on the base of the unit. Place the
camera centrally on top of the monitor, in line with the front of the screen.
R
EMEMBER THAT THERE SHOULD BE A GAP ON EACH SIDE OF THE MONITOR
.
B E CAREFUL WHEN REMOVING THE PLASTIC FILM . DO NOT PULL THE PLASTIC OFF THE MONITOR AT A 90º ANGLE AS THIS MAY DAMAGE THE
SCREEN . I NSTEAD YOU SHOULD REMOVE THE PLASTIC FILM BY PULLING IT PARALLEL WITH THE SCREEN AT A 180º ANGLE .
NOTE
NOTE
NOTE
