Guide to Knob Identification and Location
DP36 MODELS
DP30 MODEL
1 5
6
6
4 1
1 3
DP364GECS
DP364GLCS
DP366CS
DP304CS
Locate each knob type by
the corresponding number
on the diagrams. Actual
knobs are not numbered.
10
SECTION THREE: DESCRIPTION
1. XLO Knob
OFF- -HI-MED-SIM-XLO
2. Standard Knob
OFF- -HI-MED-SIM
3. Grill Knob
OFF- -LO-MED-HI
6. Oven Mode Selector
Knob
4. Griddle Knob
OFF 150 200 250 300
350 400 450 500
5. Oven Knob
OFF 150 200 250 300
350 400 450 500
Broil Clean
6 2
5
5
5
2
2
2 1 2 6
