Thermador Pro-Harmony DP36 - Manual (Page 10)

1. 22" High Shelf Backguard,
9" Low Back or 3" Island Trim
(Backguard ordered separately)
2. Burner Grates & Burners
3. Control Knobs, ExtraLow
® Burners (2)
4. Control Knobs, Standard Burners (4)
5. Oven Temperature Selector
6. Oven Mode Selector
7. Oven Door
8. Viewing Window
9. Kick Panel
10. Range Feet (4)
Dual Fuel Model DP366 - Shown
Model DP364GE – Has a center electric griddle and four burners, two ExtraLow® and two
standard.
Model DP364GL – Has a center gas grill and four burners, two ExtraLow® and two standard.
Key for DP366 Model (shown)
SECTION THREE: DESCRIPTION
Model and Parts Identification
Electric Oven Interior
11. Oven Interior Light
12. Broil Element
13. Oven Thermostat Sensor
14. Rack Guides
15. Oven Racks (3 included, not pictured)
16. Bake Element (hidden)
17. Convection Fan Cover
8
1
2
5
2
3
6
2 4
10
8
7
9
10
11
12
13
14
16
17
WARNING:
To provide proper
ventilation, do NOT
remove range feet.
4
