5–1

5 Mechanical Data

5.1

PZ (S-PQFP-G100)

PLASTIC QUAD FLATPACK

4040149 / A 03/95

50

26

0,13 NOM

Gage Plane

0,25

0,45

0,75

0,05 MIN

0,27

51

25

75

1

12,00 TYP

0,17

76

100

SQ

SQ

15,80

16,20

13,80

1,35

1,45

1,60 MAX

14,20

0

°

ā

7

°

Seating Plane

0,08

0,50

M

0,08

NOTES: A. All linear dimensions are in millimeters.

B. This drawing is subject to change without notice.

C. Falls within JEDEC MO-136
