4.15 Microcontroller Register Map
The microcontroller can access 17 locations within the TCM4300. The register locations are 8 bits wide as
shown in Table 4–16 and Table 4–17.
Table 4–16. Microcontroller Register Map
ADDR NAME D7 D6 D5 D4 D3 D2 D1 D0
00h WBDCtrl WBD_LCKD WBD_ON WBD_BW Reserved
00h WBD MSB LSB
01h FIFO MSB FIFO A(B) Microcontroller to DSP (DSP to microcontroller) LSB
02h MIntCtrl Clear WBD Clear-F Clear-D Send-C AGCEN AFCEN FMRXEN Reserved
03h SynData0 MSB LSB
04h SynData1 MSB LSB
05h SynData2 MSB LSB
06h SynData3 MSB LSB
07h SynCtrl0 SEL[2:0] LOWVAL
08h SynCtrl1 Reserved
MSB/LSB
FIRST
HIGHVAL
09h SynCtrl2 Reserved CLKPOL NUMCLKS
0Ah MCClock Reserved MSB LSB
0Bh RSSI A/D MSB LSB
0Ch BAT A/D MSB LSB
0Dh LCD D/A MSB LSD Reserved LCDEN
0Eh MStatCtrl SYNOL TXONIND SYNRDY MCLKEN CVRDY AuxFS1 AuxFS0 MPAEN
0Fh TXI Offset Reserved Sign MSB LSB
10h TXQ Offset Reserved Sign MSB LSB
