1–5
1.4
Terminal Functions (Continued)
TERMINAL
I/O
DESCRIPTION
NAME
NO.
I/O
DESCRIPTION
DSPRW
69
I
DSP read/write. A high on DSPRW enables a read operation and a low enables
a write operation to the DSP.
DSPSTRBL
68
I
DSP strobe low. The DSPSTRL (active low) is used in conjunction with DSPCSL
to enable read/write operations to the DSP.
DVDD
35, 45, 63,
75, 90
—
Digital power supply. All supply terminals must be connected together.
DVSS
34, 46, 65,
76, 91
—
Digital ground. All supply terminals must be connected together.
DWBDINT
78
O
DSP wide-band data interrupt (active low). The DWBDINT output goes low to
indicate that the wide-band data (WBD) demodulation circuits have traffic on
them.
FM
4
I
Frequency modulation. FM terminal is connected to the output of the FM
discriminator.
FMRXEN
95
O
FM receive path enable. A high output from FMRXEN can be used to enable the
power for the receiver FM path.
IQRXEN
96
O
In-phase and quadrature receive path enable. A high output on IQRXEN can be
used to enable the power for receiver I/Q path.
LCDCONTR
33
O
Liquid-crystal display (LCD) contrast. This LCDCONTR control DAC can be
used to control the amount of drive to the liquid crystal display.
MCLKOUT
67
O
Master clock out. MCLKOUT is a buffered version of MCLKIN.
MCA0
40
I
Microcontroller 5-bit parallel address bus. MCA0 through MCA4 provide a 5-bit
b
t
dd
th
i
t ll
MCA4 i th MSB
d MCA0 i th LSB
MCA1
41
p
g
p
bus to address the microcontroller. MCA4 is the MSB, and MCA0 is the LSB.
MCA2
42
MCA3
43
MCA4
44
MCCLK
62
O
Microcontroller clock. MCCLK provides an adjustable frequency with 1.215 MHz
at powerup.
MCCSH
39
I
Microcontroller interface chip-select. A high at MCCSH in conjunction with a low
at MCCSL allows the microcontroller to read from or write to the TCM4300.
MCCSL
38
I
Microcontroller interface chip-select. A low at MCCSL in conjunction with a high
at the MCCSH allows the microcontroller to read from or write to the TCM4300.
MCD0
51
I/O/Z
Microcontroller 8-bit parallel data bus. MCD0 through MCD7 provides an 8-bit
ll l d t b
t
d/
i
d t t /f
th
i
t ll
MCD7 i th
MCD1
52
p
g
p
parallel data bus to send/receive data to/from the microcontroller. MCD7 is the
MSB and MCD0 is the LSB
MCD2
53
MSB, and MCD0 is the LSB.
MCD3
54
MCD4
55
MCD5
56
MCD6
57
MCD7
58
† Z = high impedance
