Chapter 5
Installation
5.1 Chapter overview
This chapter describes the installation and the con-
nection of the QCL Starter Kit. It also explains the
operating checks before the normal use.
5.2 General
The setup procedures outlined below must be fol-
lowed meticulously to ensure that QCL Starter Kit
operates correctly and safely.
5.3 Packing list
5.3.1 Standard items
The standard starter Kit is supplied with the fol-
lowing items:
(1) QCL pulse timing unit (TPG128)
(2) CPL100 cable
(3) QCL pulse switching unit (LDD100)
(4) Low impedance line (LBI100)
(5) Laboratory Laser Housing (LLH100)
(6) CTL100 cable
(7) Temperature controller (TCU151)
(8) Power cords
1 Instructions manual
TPG
128 −TT L Pu lse Gen erato
r
O
TCU151
FF
ON Po
T
w
e
e
m
r
pera
ture
0
C
.
o
2
n
t
t
o
r
2
o
.
l
2
l
m
e
s
r
0.5 to 10.5 ms
5 to 105 m s 0 to 200 ns
−−− − − −−− −Pe riod −−− −−− −−−
−Du ratio n −
Gate IN Trig OU T
Out 1
Out 2
50 ohm s
50 ohm s
50 ohm s
max 60m A
+12 V 0 V
connected to + hi High Voltage Pulse on top, Bottom Output
Current control Max 60V
Power supply 12V
Input
LDD 100
Monitor 20 A/V, Z50 Ohm
1
2
3
4
5
7
6
Fig.13: QCL Starter Kit packing list 26
