Specifications Chapter 2
Seagate Travan 40 Product Manual Page 7
Figure 5
STT2401A (5.25-inch mount) general dimensions
Power supply specifications
The following table lists the power supply requirements for the Travan 40 drives.
Power specifications are measured at the tape drive power connector and are
nominal values.
Current and power requirements
Specification Power supply requirement
+12V DC supply +5V DC supply
Voltage tolerance ±10% ±5%
Current requirements
Seek
Load/unload
Capstan startup
Standby
0.8 amps rms
0.8 amps rms
2.0 amps rms (<200 ms)
0.03 amps rms
0.8 amps rms
0.6 amps rms
1.0 amps rms
0.5 amps rms
Ripple (peak to peak)
≤
200 mV max
≤
200 mV max
