PART 5
SPECIFICATIONS
SENSOR SPECIFICATIONS
Thermocouple Input
Temperature Range: refer to Thermocouple Chart
Temperature Accuracy: refer to Thermocouple Chart
Resolution: 1°/0.1°
Temperature Stability: 0.08°C/°C
Thermocouple Cold End Tracking: 0.05°C/°C
Thermocouple Lead Resistance: 100 ohm max.
Thermocouple Type (ITS 90): J, K, T, E, R, S, B, C, N, L
43
Input Type Range Accuracy
Iron - Constantan -210 to 760°C / -346 to 1400°F 0.4°C / 0.7°F
-270 to -160°C / -160 to 1372°C 1.0°C / 0.4°C
CHROMEGA ® - ALOMEGA ®
-454 to -256°F / -256 to 2502°F 1.8°F / 0.7°F
-270 to -190°C / -190 to 400°C 1.0°C / 0.4°C
Copper - Constantan
-454 to -310°F / -310 to 752°F 1.8°F / 0.7°F
-270 to -220°C / -220 to 1000°C 1.0°C / 0.4°C
CHROMEGA
®
- Constantan -454 to -364°F / -364 to 1832°F 1.8°F / 0.7°F
-50 to 40°C / 40 to 1768°C 1.0°C / 0.5°C
Pt / 13%Rh-Pt
-58 to 104°F / 104 to 3214°F 1.8°F / 0.9°F
-50 to 100°C / 100 to 1768°C 1.0°C / 0.5°C
Pt / 10%Rh-Pt
-58 to 212°F / 212 to 3214°F 1.8°F / 0.9°F
100 to 640°C / 640 to 1820°C 1.0°C / 0.5°C
30%Rh-Pt / 6%Rh-Pt
212 to 1184°F / 1184 to 3308°F 1.8°F / 0.9°F
5%Re-W / 26%Re-W 0 to 2320°C / 32 to 4208°F 0.4°C / 0.7°F
-250 to -100°C / -100 to 1300°C 1.0°C / 0.4°C
Nicrosil - Nisil
-418 to -148°F / -148 to 2372°F 1.8°F / 0.7°F
J DIN -200 to 900°C / -328 to 1652°F 0.4°C / 0.7°F
L
